HT.HP. Soft Over Flow
HTHP Soft Over Flow is just like the HTHP Soft Flow machine with a bigger capacity & for heavy fabrics.
HTHP Soft Over Flow is Specially Designed to process Heavy and sensitive fabrics like Terry Towel, and Curtain Bedsheet of 100% Cotton knit and woven fabrics. In short, it’s a Terry towel dyeing machine.
HTHP Soft Over Flow can work as a Soft Overflow with minor adjustments.
A larger nozzle diameter, with a Higher volume & low-pressure nozzle design and inside Teflon sheet are helpful to move the fabric very smoothly and gently without damaging the cloth.
A specially develop online filter design helps to collect the Terry towel fumes.
🔸 Technical Specification
✅ Capacity: 50 to 2000 kg.
✅ The process has a sensitive fabric like Terry Towels, Curtain, Bed Sheet, 100% cotton knit & woven etc.
✅ Work as Soft flow or as overflow dyeing.
✅ High Temp. – Up to 140 ° C.
✅ The vessel makes of stainless steel 316 L.
✅ Specially developed a filter to collect towel fumes.
✅ Teflon Sheet inside the chamber for smooth fabric movement.
✅ High volume, Low-pressure soft nozzle with a larger diameter for heavy and Larger width fabrics
✅ Fabric drive reel with frequency controller.
₹1,450,000.00
Compare
HTHP Soft Over Flow
HTHP Soft Over Flow is just like the HTHP Soft Flow machine with a bigger capacity & for heavy fabrics.
HTHP Soft Over Flow is Specially Designed to process Heavy and sensitive fabrics like Terry Towel, Curtain Bedsheet of 100% Cotton knit and woven fabrics.
HTHP Soft Over Flow can work as a Soft Over flow with minor adjustments.
A larger nozzle diameter, with a Higher volume & low-pressure nozzle design and inside Teflon sheet are helpful to move the fabric very smoothly and gently without damaging the cloth.
A specially develop online filter design helps to collect the Terry towel fumes.
🔸 Technical Specification
✅ Capacity: 50 to 2000Kg.
✅ The process has a sensitive fabric like Terry Towel, Curtain, Bed Sheet, 100% cotton knit & woven etc.
✅ Work as Soft flow or as overflow dyeing.
✅ High Temp. – Up to 140 ° C.
✅ The vessel makes of stainless steel 316 L.
✅ Specially developed a filter to collect towel fumes.
✅ Teflon Sheet inside the chamber for smooth fabric movement.
✅ High volume, Low-pressure soft nozzle with a larger diameter for heavy and Larger width fabrics
✅ Fabric drive reel with frequency controller.
🔸 Payment, Taxes and Delivery
Payment: Before dispatch of machinery, 40% advance and a balance against the proforma invoice.
Delivery: Delivery of machine ideally comes within 4 to 6 weeks.
Freight: Will be paid by the customer.
Sales Tax: GST 18% (Domestic Orders) Or Vat 4% +1% No CST against form “H”( export orders).
Installation: Will be charged extra per machine over and above the price.
1. Select Product
Choose the required specification & submit the details.
2. Get Offer
Get a Detailed Offer.
3. Pay The Advance
Pay the advance amount as per agreed terms.
4. Product Under Construction
Product goes under Construction according agreed time.
5. Pay The Rest Amount
Pay the balance amount as your machine get ready to dispatch.
6. Shipment Initiated
Shipment option available through Manufacturer.
7. Installation
Finally, the product will be installed at your plant.
| Capacity 250 Kgs/ Chamber | 50 Kgs, 250 Kgs, 500 Kgs, 750 Kgs, 1000 Kgs, 1250 Kgs, 1500 Kgs, 1750 Kgs, 2000 Kgs |
|---|---|
| Fabric | COTTON, TERRY TOWEL, CURTAIN, WOVEN, KNITTED |
