Long Tube Jet
Long tube Jet dyeing machine working concept is same compare with Convention Rapid long tube jet dyeing machine. Though the major advantage of this machine is liquor ration is nearly half than conventional rapid Jet dyeing machine. In this machine fabric does not float but it run nearly in dry condition. Another benefit of this machine is it’s single vessel with two chamber design. Due to this design fabric loop length is reduce additionally bringing down the running cost, capital cost as well as processing time.
[spbsm-follow-buttons]
₹1,800,000.00
Compare
Long Tube Jet
Long tube Jet dyeing machine working concept is same compare with Convention Rapid long tube jet dyeing machine. Though the major advantage of this machine is liquor ration is nearly half than conventional rapid Jet dyeing machine. In this machine fabric does not float but it run nearly in dry condition.
Another benefit of this machine is it’s single vessel with two chamber design. Due to this design fabric loop length is reduce additionally bringing down the running cost, capital cost as well as processing time.
Technical Specification
- Capacity : 250 to 400Kg.
- Dye – 30 To 450 Grams/Meter. Sq. Fabrics (Woven & Knitted Fabrics)
- Low Liquor ratio: 1:3 to 1:4 (Wet fabric)
- High Temp. – Up to 140 ° C.
- Vessel made from – SS 316 L
- Single Vessel two chamber to reduce the loop length as well as process time.
- Inside PTFE Teflon sheet for entangle operation.
- Online washing system.
- Specially design bow jet nozzle for extra force.
- Fabric drive reel with frequency controller.
Payment, Taxes and Delivery
Payment: 40% Advance & Balance against Proforma Invoice prior to dispatch.
Delivery: Delivery of machine is ideally comes within 4 to 6 weeks.
Freight: Will be paid by the customer.
Sales Tax: GST 18% (Domestic Orders) Or Vat 4% +1% No CST against form “H”( Export Orders).
Erection: Will be charged extra per machine over and above given price.
1. Select Product
Choose the required specification & submit the details.
2. Get Offer
Get a Detailed Offer.
3. Pay The Advance
Pay the advance amount as per agreed terms.
4. Product Under Construction
Product goes under Construction according agreed time.
5. Pay The Rest Amount
Pay the balance amount as your machine get ready to dispatch.
6. Shipment Initiated
Shipment option available through Manufacturer.
7. Installation
Finally, the product will be installed at your plant.
| Capacity | 250 Kgs, 300 Kgs, 400 Kgs |
|---|---|
| Fabric | WOVEN, KNITTED |
